Weight

870 kg

Dimensions

198.3 × 103.3 × 126.4 cm

Brand

Baudouin

Product Type

Diesel Engine

Prime Power (kW)

240kW

Standby Power(kW)

264kW

Prime Power

250kVA

Standby Power

275kVA

Cylinders

Cylinders: 6, Valves: 12

Cylinder Arrangement

Inline

Bore × Stroke

126mm x 130mm

Displacement

9.726L

Thermodynamic Cycle

Diesel 4 Stroke

Mean Piston Speed (m/s)

6.5 m/s

BMEP @ ESP (Bar)

21.71 Bar

Cooling System

Liquid (water + 50% antifreeze)

Injection System

Direct Injection

Fuel System

Mechanical Pump

Aspiration

Turbo Charged with Aftercooler

Compression Ratio

17 : 1

Flywheel Housing (SAE)

SAE NO.1

Flywheel Clutch Size (Inches)

14"

Teeth on Flywheel Ring Gear

136 Teeth

Inertia of flywheel (kg•m²)

1.84 kg•m²

Inertia of crankshaft (kg•m²)

0.39 kg•m²

Emission Standard

N/A

Air Intake Temperature Rise

≤ 15°C

Recommended Air Flow @ PRP (m³/min)

16.8 m³/min

Minimum Diameter of Intake Pipe (mm)

100mm

Aftercooler System Type

Air to Air

Oil Capacity (L)

High Level: 22 litres, Low Level: 19 litres

Oil pressure in normal condition at 1500 Rpm @ PRP (Bar)

3.5 Bar – 5.8 Bar

Maximum Oil temperature (°C)

105°C

Oil Flow at 1500RPM (L/min)

118 L/min

Total Heat Dissipation @ ESP (kJ/s)

378.3 kJ/s

Maximum Exhaust Back Pressure (mBar)

60 mBar

Maximum Exhaust Temperature Before Turbocharger (°C)

700°C

Maximum Exhaust Temperature After Turbocharger (°C)

600°C

Exhaust Gas Flow

46.8 m³/min

Minimum Diameter of Exhaust Pipe (mm)

100mm

Maximum Bending Moment of Exhaust Gas Exit Flange (Nm)

10 Nm

Governor

Electronic Regulator

Governor Steady State Speed Stability at Constant Load (ISO 8528-5 Class G3)

≤ +/- 0.5 %

Fuel Supply Flow (L/hr)

169 L/hr

Fuel Type

Diesel Fuel Oil

Electrical System Voltage (negative to ground) (Vdc)

24Vdc

Starter Power (kW)

8.5kW

Battery Charger Current (A)

55A

Battery Charger Absorbed Power (kW)

1.54kW

Diesel Engine Noise (Acoustic Power Level) (dB(A))

113.5 dB

Fuel Consumption @ 100%

56.9 l/h

Fuel Consumption @ 75%

42.2 l/h

Fuel Consumption @ 50%

28.3 l/h

Fuel Consumption @ 25%

15.4 l/h

A partner in power generation

World Class Manufacturing, Fast Regional Distribution

The Generator King is the sole authorised distributor of StromerPower Alternators in Sub-Saharan Africa. By dealing with us directly you cut out the middlemen, saving you time and money.

Every engine, alternator, and spare part we supply is built to international standards and fully tested to handle tough conditions. Whether you are a local generator builder looking for a StromerPower alternator, a diesel engine, OEM spare parts or a business needing a complete power setup, we ensure fast delivery, large stock availability and reliable performance.

GET A QUOTE

STROMERPOWER FACTORY | MANUFACTURING & ASSEMBLY LINE

Our Delivery Channels

Sub-Saharan Logistics

Name: Baudouin 264kW Diesel Engine 6M16G275/5 | Baudouin
Brand: Baudouin
SKU: 6M16G275/5

We ship StromerPower alternators, leading brand diesel engines and OEM diesel generators as well as OEM spare parts throughout South Africa and across the continent, including Namibia, Botswana, Malawi, Mozambique, Zambia, Zimbabwe, Swaziland, and Lesotho.

Our team handles the entire logistics process, from factory loading to cross border transport, ensuring your equipment arrives safely and on time.

We hold a large volume of stock and genuine replacement parts at our warehouses so we can supply clients across Africa quickly and efficiently.

CALL US: +27 10 012 6417

Baudouin 264kW Diesel Engine 6M16G275/5

Need help choosing the right product?

Baudouin was founded in 1918 and is a premier diesel engine manufacturer. They are ISO9001, ISO14001 and ISO45001 certified, which is testament to their quality and reliability.

Baudouin 264kW Diesel Engine

Dependable 9.7L Power
The 6M16G275/5 uses a 9.7 litre six cylinder inline engine design to provide steady mechanical power for large sites. It couples with alternators to power industrial facilities, large pump systems, agricultural equipment and commercial properties during main grid blackouts.

Turbocharging and Charge Cooling
The engine pairs forced turbocharging with an air-to-air intercooler to optimise intake air density. This setup increases combustion efficiency, allowing the engine to absorb load connections smoothly while keeping electrical frequencies stable.

Fuel Delivery and Speed Control
A mechanical inline fuel pump works together with an electronic speed governor to monitor engine RPM. This design adjusts fuel flow under varying load demands, maintaining consistent engine speed and keeping fuel consumption predictable.

Temperature Management
Built with expanded fluid jackets and a powerful radiator, the engine operates in ambient heat up to 50°C. The internal cooling loop distributes fluid evenly across all six cylinders to prevent thermal damage during long operational cycles.

PRODUCT SPECIFICATIONS
